Value-Engineered Stadium & Field Lighting System
Cost-effective LED stadium and field lighting system designed for schools and municipal sports venues. The Union Series delivers reliable coverage, controlled glare, and durable performance for value-oriented field lighting upgrades
Performance engineering ensures our fixtures withstand harsh environments while delivering consistent light output.
| Feature | Specification |
|---|---|
| Wattages | 300W / 400W / 500W / 600W |
| Lumen Output | Up to 78,000 lm |
| CCT | 3000K / 4000K / 5000K / 5700K (Standard 5700K) |
| CRI | 70 / 80 / 90 CRI (70 CRI standard) |
| Voltage | 100–277V / 277–480V |
| Beam Optics | 25° / 45° / 60° Precision Optics |
| IP Rating | IP65 / IP66 Optional (IP67/68 internal components) |
| Lifespan | L70 ≥ 50,000 hrs |
| Warranty | 10 Years |
